Watlow EZ-ZONE

®

PM Integrated Controller

49

Chapter 4 Home Page

Data Type R/W

uint = Unsigned 16 bit

integer

dint = Signed 32-bit,

long

string = ASCII (8 bits

per character)

float = IEEE 754 32-bit
RWES = Readable

Writable

EEPROM (saved)

User Set (saved)

Display

Visual information from the control is displayed to the observer using a fairly standard 7 segment display.

Due to the use of this technology, several characters displayed need some interpretation, see the list below:

[1]

= 1

[0]

= 0

[i]

= i

[r]

= r

[2]

= 2

[a ]

= A

[j ]

= J

[S]

= S

[3]

= 3

[ b]

= b

[H]

= K

[ t]

= t

[4]

= 4

[c]

, [C] = c

[ l]

= L

[U]

= u

[5]

= 5

[d ]

= d

[ m ]

= M

[u]

= v

[6]

= 6

[ e]

= E

[n]

= n

[ w ]

= W

[7]

= 7

[ f]

= F

[o]

= o

[y ]

= y

[8]

= 8

[g ]

= g

[ p]

= P

[2]

= Z

[9]

= 9

[ h]

= h

[q ]

= q

Range

Within this column notice that on occasion there will be numbers found within parenthesis. This number

represents the enumerated value for that particular selection. Range selections can be made simply by writ-

ing the enumerated value of choice using any of the available communications protocols. As an example, turn

to the Setup Page and look at the Analog Input [`Ai] menu and then the Sensor Type [Sen] prompt. To turn

the sensor off using Modbus simply write the value of 62 (off) to register 368 and send that value to the con-

trol.

Communication Protocols

When using a communications protocol in conjunction with the EZ-ZONE PM there are two possible ports

(instances) used. Port 1 or instance 1 is always dedicated to Standard Bus communications. This same in-

stance can also be used for Modbus RTU if ordered. Depending on the controller part number port 2 (in-

stance 2) can be used with Modbus, CIP and Profibus. For further information read through the remainder

of this section.

Modbus Introduction to the Modbus Protocol

Gould Modicon, now called AEG Schneider, first created the protocol referred to as "Modbus RTU" used in

process control systems. Modbus provides the advantage of being extremely reliable in exchanging informa-

tion, a highly desirable feature for industrial data communications. This protocol works on the principle of

packet exchanges. The packet contains the address of the controller to receive the information, a command

field that says what is to be done with the information, and several fields of data. Each PM parameter has

a unique Modbus address and they can be found in the following Operations, Setup, Profiling, and Factory

Pages.

Conventions Used in the Menu Pages (cont.)
