Watlow EZ-ZONE ® PM Integrated Controller • 107 • Chapter 7 Profiling Page
Profiling Page
Dis-
play
Parameter Name
Description
Range Default
Modbus
Relative Ad-
dress
CIP
Class
Instance
Attribute
hex (dec)
Param-
eter ID
Data
Type
&
Read/
Write
[``P1]
[prof]
Profiling Menu
[``p1]
[ P1] to
[``p4]
[ P4] Profile [1 to 4] Step
Select a step to edit or view.
1 to 10 [profile 1]
11 to 20 [profile 2]
21 to 30 [profile 3]
31 to 40 [profile 4]
- - - - - - - - - - - - - - - -
[S;typ]
[S.typ] Step Type
Select a step type.
Note:
Prior to selecting the Step Type
consider whether or not profiles
will be based on time or rate of
change. By default, profiles are
configured for Time [``ti].
Therefore, Rate will not be
available here. If it is desired to
base profiles on rate of change,
navigate to the Setup Page and
then the Global Menu where
Ramping Type can be
changed from Time to Rate.
[UStP] Unused Step (50)
[`End] End (27)
[``JL] Jump Loop (116)
[CloC] Wait For Time (1543)
[W;bo] Wait For Both (210)
[W;Pr] Wait For Process (209)
[`W;E] Wait For Event (144)
[SoAH] Soak (87)
[``ti] Time (143)
[rate] Rate (81)
Unused Instance 1
Map 1 Map 2
2570 4500
Offset to next
instance (Map
1 equals +50,
Map 2 equals
+100)
0x79 (121)
1 to 40
1
21001 uint
RWE
[t;SP1]
[t.SP1] Step Type Parameters
Target Set Point Loop 1
When Step Type is Time or
Rate, enter the closed loop set
point for loop 1 to ramp to for
this step.
-1,999.000 to 9,999.000°F or
units
-1,128 to 5,537.000°C
0.0°F or
units
-18°C
Instance 1
Map 1 Map 2
2572 4502
Offset to next
instance (Map
1 equals +50,
Map 2 equals
+100)
0x79 (121)
1 to 40
2
21002 float
RWE
[t;SP2]
[t.SP2] Step Type Parameters
Target Set Point Loop 2
When Step Type is Time or
Rate, enter the closed loop set
point for loop 2 to ramp to for
this step.
-1,999.000 to 9,999.000°F or
units
-1,128 to 5,537.000°C
0.0°F or
units
-18°C
Instance 1
Map 1 Map 2
- - - - 4554
Offset to next
instance Map 2
equals +100
0x79 (121)
1 to 40
0x1C (28)
21028 float
RWE
[hoUr]
[hoUr] Step Type Parameters
Hours
Select the hours (plus Minutes
and Seconds) for a timed step.
0 to 99 0 Instance 1
Map 1 Map 2
2574 4504
Offset to next
instance (Map
1 equals +50,
Map 2 equals
+100)
0x79 (121)
1 to 40
3
21003 uint
RWE
[Min]
[Min] Step Type Parameters
Minutes
When Step Type is Time, Soak,
or Wait For Time enter Minutes
(plus Hours and Seconds) for
this step.
0 to 59 0 Instance 1
Map 1 Map 2
2576 4506
Offset to next
instance (Map
1 equals +50,
Map 2 equals
+100)
0x79 (121)
1 to 40
4
21004 uint
RWE
Note:
Some values will be rounded off to fit in the four-character display. Full values can be read with other
interfaces. R: Read
W: Write
E: EEPROM
S: User Set
