Watlow EZ-ZONE

®

PM Integrated Controller

90

Chapter 6 Setup Page

Setup Page

Dis-

play

Parameter Name

Description

Range

Default

Modbus Rela-

tive

Address

CIP

Class

Instance

Attribute

hex (dec)

Pro-

fibus

Index

Param-

eter ID

Data

Type

&

Read/

Write

[`A;hi]
[ A.hi]

Alarm (1 to 4)

Alarm High Set Point

If Alarm Type (Setup

Page, Alarm Menu) is

set to:

process - set the process

value that will trigger

a high alarm.

deviation - set the span

of units from the closed

loop set point that will

trigger a high alarm.

-1,999.000 to 9,999.000°F or

units

-1,128.000 to 5,537.000°C

300.0°F

or units

150.0°C

Instance 1

Map 1 Map 2

1480 1880

Offset to next

instance (Map

1) equals +50

Offset to next

instance (Map

2) equals +60

0x6D

(109)

1 to 4

1

19

9001

float

RWES

[`A;LA]
[ A.LA]

Alarm (1 to 4)

Alarm Latching

Turn alarm latching on

or off. A latched alarm

has to be turned off by

the user.

[nLAt]

Non-Latching (60)

[`LAt]

Latching (49)

Non-

Latching

Instance 1

Map 1 Map 2

1492

1892

Offset to next

instance (Map

1 equals +50,

for Map 2

equals +60)

0x6D (109)

1 to 4

7

27

9007

uint

RWES

[`A;bL]
[ A.bL]

Alarm (1 to 4)

Alarm Blocking

Select when an alarm

will be blocked. After

startup and/or after the

set point changes, the

alarm will be blocked

until the process value

enters the normal range.

[`oFF]

Off (62)

[`Str]

Startup (88)

[StPt]

Set Point (85)

[both]

Both (13)

Off

Instance 1

Map 1 Map 2

1494 1894

Offset to next

instance (Map

1 equals +50,

for Map 2

equals +60)

0x6D (109)

1 to 4

8

28

9008

uint

RWES

[`A;Si]
[ A.Si]

Alarm (1 to 4)

Alarm Silencing

Turn alarm silencing on

to allow the user to dis-

able this alarm.

[`oFF]

Off (62)

[``on]

On (63)

Off

Instance 1

Map 1 Map 2

1490

1890

Offset to next

instance (Map

1 equals +50,

for Map 2

equals +60)

0x6D (109)

1 to 4

6

29

9006

uint

RWES

[A;dSP]
[A.dSP]

Alarm (1 to 4)

Alarm Display

Display an alarm mes-

sage when an alarm is

active.

[`oFF]

Off (62)

[``on]

On (63)

On

Instance 1

Map 1 Map 2

1510

1910

Offset to next

instance (Map

1 equals +50,

for Map 2

equals +60)

0x6D (109)

1 to 4

0x10 (16)

30

9016

uint

RWES

[`A;dL]
[ A.dL]

Alarm (1 to 4)

Alarm Delay Time

Set the span of time that

the alarm will be delayed

after the process value

exceeds the alarm set

point.

0 to 9,999 seconds

0

Instance 1

Map 1 Map 2

1520

1920

Offset to next

instance (Map

1 equals +50,

for Map 2

equals +60)

0x6D (109)

1 to 4

0x15 (21)

31

9021

uint

RWES

Note:
Some values will be rounded off to fit in the four-character display. Full values can be read
with other interfaces.

R: Read

W: Write

E:

EEPROM

S:

User

Set
