Chapter 6 Setup Page
Setup Page
Dis-
play
Parameter Name
Description
Range
Default
Modbus Rela-
tive
Address
CIP
Class
Instance
Attribute
hex (dec)
Pro-
fibus
Index
Param-
eter ID
Data
Type
&
Read/
Write
[`r;Sr]
[ r.Sr]
Output Process (1 or 3)
Retransmit Source
Select the value that will
be retransmitted.
[``Ai]
Analog Input (142)
[StPt]
Set Point (85)
[CUrr]
Current (22)
[``Pu]
Process Value (241)
Analog
Input
Instance 1
Map 1 Map 2
724
844
Instance 3
Map 1 Map 2
804
924
0x76 (118)
1 or 3
3
97
18003 uint
RWES
[``Fi]
[ Fi]
Output Process (1 or 3)
Output Function In-
stance
Set the instance of the
function selected above.
1 to 4
1
Instance 1
Map 1 Map 2
726
846
Instance 3
Map 1 Map 2
806
926
0x76 (118)
1 or 3
4
98
18004 uint
RWES
[`S;Lo]
[ S.Lo]
Output Process (1 or 3)
Scale Low
Set the scale low for pro-
cess output in electrical
units. This value; in volts
or milliamps, will cor-
respond to 0% PID power
output or range low re-
transmit output.
-100.0 to 100.0
0.00
Instance 1
Map 1 Map 2
736
856
Instance 3
Map 1 Map 2
816
936
0x76 (118)
1 or 3
9
99
18009 float
RWES
[`S;hi]
[ S.hi]
Output Process (1 or 3)
Scale High
Set the scale high for
process output in
electrical units. This
value; in volts or
milliamps, will corre-
spond to 100% PID
power output or range
high retransmit output.
-100.0 to 100.0
10.00
Instance 1
Map 1 Map 2
738
858
Instance 3
Map 1 Map 2
818
938
0x76 (118)
1 or 3
0xA (10)
100
18010 float
RWES
[`r;Lo]
[ r.Lo]
Output Process (1 or 3)
Range Low
Set the minimum value
of the retransmit value
range in process units.
When the retransmit
source is at this value,
the retransmit output
will be at its Scale Low
value.
-1,999.000 to 9,999.000°F or
units
-1,128.000 to 5,537.000°C
0.0°F or
units
-18°C
Instance 1
Map 1 Map 2
740
860
Instance 3
Map 1 Map 2
820
940
0x76 (118)
1 or 3
0xB (11)
101
18011 float
RWES
[`r;hi]
[ r.hi]
Output Process (1 or 3)
Range High
Set the maximum value
of the retransmit value
range in process units.
When the retransmit
source is at this value,
the retransmit output
will be at its Scale High
value.
-1,999.000 to 9,999.000°F or
units
-1,128.000 to 5,537.000°C
100.0°F or
units
38.0°C
Instance 1
Map 1 Map 2
742
862
Instance 3
Map 1 Map 2
822
942
0x76 (118)
1 or 3
0xC (12)
102
18012 float
RWES
Note:
Some values will be rounded off to fit in the four-character display. Full values can be read
with other interfaces.
R: Read
W: Write
E:
EEPROM
S:
User
Set
