Page 91
Watlow EZ-ZONE
®
PM Integrated Controller
•
88
•
Chapter 6 Setup Page
Setup Page
Dis-
play
Parameter Name
Description
Range
Default
Modbus Rela-
tive
Address
CIP
Class
Instance
Attribute
hex (dec)
Pro-
fibus
Index
Param-
eter ID
Data
Type
&
Read/
Write
[`o;lo]
[ o.Lo]
Output Process (1 or 3)
Output Low Power
Scale
The power output will
never be less than the
value specified and will
represent the value at
which power scaling
begins.
0.0 to 100%
0.0%
Instance 1
Map 1 Map 2
744
864
Instance 3
Map 1 Map 2
824
944
0x76 (118)
1 or 3
0x0D (13)
103
18013 float
RWES
[`o;hi]
[ o.hi]
Output Process (1 or 3)
Output High Power
Scale
The power output will
never be greater than
the value specified and
will represent the value
at which power scaling
stops.
0.0 to 100%
100%
Instance 1
Map 1 Map 2
746
866
Instance 3
Map 1 Map 2
826
946
0x76 (118)
1 or 3
0x0E (14)
104
18014 float
RWES
[`o;CA]
[ o.CA]
Output Process (1 or 3)
Calibration Offset
Set an offset value for a
process output.
-1,999.000 to 9,999.000°F or
units
-1,110.555 to 5,555.000°C
0.0°F or
units
0.0°C
Instance 1
Map 1 Map 2
732
852
Instance 3
Map 1 Map 2
812
932
0x76 (118)
1 or 3
7
105
18007 float
RWES
[Alm]
[`Set]
Alarm Menu
[`A;ty]
[ A.ty]
Alarm (1 to 4)
Alarm Type
Select whether the alarm
trigger is a fixed value or
will track the set point.
[`oFF]
Off (62)
[PR;AL]
Process Alarm (76)
[dE;AL]
Deviation Alarm (24)
Off
Instance 1
Map 1 Map 2
1508
1908
Offset to next
instance (Map
1 +50, Map 2
+60)
0x6D (109)
1 to 4
0xF (15)
20
9015
uint
RWES
[`Sr;A]
[ Sr.A]
Alarm (1 to 4)
Alarm Source
Select what will trigger
this alarm.
Note:
When using Deviation
Alarms with Differen-
tial control, the Alarm
Source must be set to
Process Value.
[``Ai]
Analog Input (142)
[PWr]
Power (73)
[``Pu]
Process Value (241)
[`Lnr]
Linearization (238)
[CUrr]
Current (22)
Instance 1
Map 1 Map 2
1512 1912
Offset to next
instance (Map
1 +50, Map 2
+60)
0x6D (109)
1 to 4
0x11 (17)
21
9017
uint
RWES
[`is;A]
[ iS.A]
Alarm (1 to 4)
Alarm Source Instance
Set the instance of the
function selected above.
1 or 2
1
Instance 1
Map 1 Map 2
1514
1914
Offset to next
instance (Map
1 +50, Map 2
+60)
0x6D (109)
1 to 2
0x12 (18)
22
9018
uint
RWES
Note:
Some values will be rounded off to fit in the four-character display. Full values can be read
with other interfaces.
R: Read
W: Write
E:
EEPROM
S:
User
Set
