Watlow EZ-ZONE

®

PM Integrated Controller

84

Chapter 6 Setup Page

Setup Page

Dis-

play

Parameter Name

Description

Range

Default

Modbus Rela-

tive

Address

CIP

Class

Instance

Attribute

hex (dec)

Pro-

fibus

Index

Param-

eter ID

Data

Type

&

Read/

Write

[``rP]

[ rP]

Control Loop (1 to 2)

Ramp Action

Select when the control-

ler's set point will ramp

to the defined end set

point.

[`oFF]

Off (62)

[`Str]

Startup (88)

[StPt]

Set Point Change (85)

[both]

Both (13)

Off

Instance 1

Map 1 Map 2

2186

2666

Instance 2

Map 1 Map 2

2266 2746

0x6B (107)

1 to 2

0xE (14)

56

7014

uint

RWES

[`r;SC]

[ r.SC]

Control Loop (1 to 2)

Ramp Scale

Select the scale of the

ramp rate.

[hoUr]

Hours (39)

[Min]

Minutes (57)

Minutes

Instance 1

Map 1 Map 2

2188

2668

Instance 2

Map 1 Map 2

2268 2748

0x6B (107)

1 to 2

0xF (15)

57

7015

uint

RWES

[`r;rt]

[ r.rt]

Control Loop (1 to 2)

Ramp Rate

Set the rate for the set

point ramp. Set the time

units for the rate with

the Ramp Scale param-

eter.

0.0 to 9,999.000°F or units

0.0 to 5,555.000°C

1.0°F or

units

1.0°C

Instance 1

Map 1 Map 2

2192

2672

Instance 2

Map 1 Map 2

2272 2752

0x6B (107)

1 to 2

0x11 (17)

58

7017

float

RWES

[`L;SP]
[ L.SP]

Control Loop (1 to 2)

Low Set Point

Set the minimum value

of the closed loop set

point range.

-1,999.000 to 9,999.000°F or

units

-1,128.000 to 5,537.000°C

-1,999°F

or units

-1,128°C

Instance 1

Map 1 Map 2

2164

2644

Instance 2

Map 1 Map 2

2244 2724

0x6B (107)

1 to 2

3

52

7003

float

RWES

[`h;SP]
[ h.SP]

Control Loop (1 to 2)

High Set Point

Set the maximum value

of the closed loop set

point range.

-1,999.000 to 9,999.000°F or

units

-1,128.000 to 5,537.000°C

9,999°F

or units,

5,537°C

Instance 1

Map 1 Map 2

2166

2646

Instance 2

Map 1 Map 2

2246 2726

0x6B (107)

1 to 2

4

53

7004

float

RWES

[`C;SP]
[ C.SP]

Control Loop (1 to 2)

Closed Loop Set Point

Set the set point that

the controller will auto-

matically control to.

Low Set Point to High Set

Point (Setup Page)

75.0°F or

units

24.0°C

Instance 1

Map 1 Map 2

2160 2640

Instance 2

Map 1 Map 2

2240

2720

0x6B

(107)

1 to 2

1

49

7001

float

RWES

[`id;S]
[ id.S]

Control Loop (1 to 2)

Idle Set Point

Set a closed loop set

point that can be trig-

gered by an event state.

Low Set Point to High Set

Point (Setup Page)

75.0°F or

units

24.0°C

Instance 1

Map 1 Map 2

2176 2656

Instance 2

Map 1 Map 2

2197

2736

0x6B

(107)

1 to 2

9

50

7009

float

RWES

[SP;Lo]
[SP.Lo]

Control Loop (1 to 2)

Set Point Open Limit

Low

Set the minimum value

of the open-loop set point

range.

-100 to 100%

-100

Instance 1

Map 1 Map 2

2168

2648

Instance 2

Map 1 Map 2

2248 2728

0x6B (107)

1 to 2

5

54

7005

float

RWES

Note:
Some values will be rounded off to fit in the four-character display. Full values can be read
with other interfaces.

R: Read

W: Write

E:

EEPROM

S:

User

Set
