Watlow EZ-ZONE

®

PM Integrated Controller

57

Chapter 5 Operations Page

Operations Page

Dis-

play

Parameter name

Description

Range

Default

Modbus

Relative Ad-

dress

CIP

Class

Instance

Attribute

hex (dec)

Profibus

Index

Param-

eter ID

Data

Type

& Read/

Write

[LiM]
[oPEr]
Limit Menu

[`LL;S]
[ LL.S]

Limit (1)

Limit Low Set Point

Set the low process

value that will trigger

the limit.

-1,999.000 to 9,999.000°F

or units

-1,128.000 to 5,537.000°C

0.0°F or

units

-18.0°C

Instance 1

Map 1

Map 2

684

724

0x70 (112)

1

3

38

12003 float

RWES

[`Lh;S]
[ Lh.S]

Limit (1)

Limit High Set Point

Set the high process

value that will trigger

the limit.

-1,999.000 to 9,999.000°F

or units

-1,128.000 to 5,537.000°C

0.0°F or

units

-18.0°C

Instance 1

Map 1

Map 2

686

726

0x70 (112)

1

4

39

12004 float

RWES

No

Dis-

play

Limit (1)

Limit State

Clear limit once limit

condition is cleared.

[`off]

Off (62)

[none]

None (61)

[`li;h]

Limit High (51)

[`li;l]

Limit Low (52)

[`err]

Error (28)

- - - -

Instance 1

Map 1

Map 2

690

730

0x70 (112)

1

6

- - - -

12006 uint

R

[`lCr]
[ LCr]

Limit (1)

Limit Clear Request

Clear limit once limit

condition is cleared.

[`Clr]

Clear (0)

[ignr]

Ignore (204)

- - - -

Instance 1

Map 1

Map 2

680

720

0x70 (112)

1

1

- - - -

12001 uint

W

[`l;st]
[ L.St]

Limit (1 to 4)

Limit Status

Reflects whether or not

the limit is in a safe or

failed mode.

[fail]

Fail (32)

[safe]

Safe (1667)

- - - -

Instance 1

Map 1

Map 2

- - - -

744

0x70 (112)

1

0x0D (13)

- - - -

12013 uint

R

[Mon]
[oPEr]
Monitor Menu

[C;MA]
[C.MA]

Monitor (1 to 2)

Control Mode Active

View the current control

mode.

[`off]

Off (62)

[AUto]

Auto (10)

[MAn]

Manual (54)

Instance 1

Map 1

Map 2

1882 2362

Instance 2

Map 1

Map 2

1952

2432

0x97 (151)

1 to 2

2

- - - -

8002

uint

R

[`h;Pr]
[ h.Pr]

Monitor (1 to 2)

Heat Power

View the current heat

output level.

0.0 to 100.0%

0.0

Instance 1

Map 1

Map 2

1904 2384

Instance 2

Map 1

Map 2

1974

2454

0x97 (151)

1 to 2

0xD (13)

- - - -

8011

float

R

[`C;Pr]
[ C.Pr]

Monitor (1 to 2)

Cool Power

View the current cool

output level.

-100.0 to 0.0%

0.0

Instance 1

Map 1

Map 2

1906 2386

Instance 2

Map 1

Map 2

1976

2456

0x97 (151)

1 to 2

0xE (14)

- - - -

8014

float

R

[`C;SP]
[ C.SP]

Monitor (1 to 2)

Closed Loop Set Point

View the set point cur-

rently in effect.

-1,999.000 to 9,999.000°F

or units

-1,128.000 to 5,537.000°C

Instance 1

Map 1

Map 2

2172 2652

Instance 2

Map 1

Map 2

2252

2732

0x6B (107)

1 to 2

7

- - - -

8029

float

R

Note:
Some values will be rounded off to fit in the four-character display. Full values can
be read with other interfaces.

R: Read

W: Write

E: EEPROM

S: User

Set
