Watlow EZ-ZONE ® PM Integrated Controller • 44 • Chapter 3 Keys and Displays
Navigating the EZ-ZONE PM Integrated Controller
®
[`` Ai ]
[` Set ]
®
[`` 70 ]
[` `72 ]
Home Page from anywhere: Press the Infinity Key ˆ for two seconds to return to the Home Page.
®
[`` 70 ]
[` `72 ]
®
[`` Ai ]
[ oper ]
Operations Page from Home Page: Press both the Up ¿ and Down ¯ keys for three seconds.
®
[`` 70 ]
[` `72 ]
®
[`` Ai ]
[` Set ]
Setup Page from Home Page: Press both the Up ¿ and Down ¯ keys for six seconds.
®
[`` 70 ]
[` `72 ]
®
[`` p1 ]
[ prof ]
Profiling Page from Home Page: Press the Advance Key ‰ for three seconds
®
[`` 70 ]
[` `72 ]
®
[ Cust ]
[ fCty ]
Factory Page from Home Page: Press both the Advance ‰ and Infinity ˆ keys for six
seconds.
Note:
Keys must be held continuously
until [`SEt] is displayed in green.
If keys are released when [OPEr]
is displayed, press the infinity key
or reset key to exit and repeat until
[`SEt]
is displayed.
