Watlow EZ-ZONE

®

PM Integrated Controller

81

Chapter 6 Setup Page

Setup Page

Dis-

play

Parameter Name

Description

Range

Default

Modbus Rela-

tive

Address

CIP

Class

Instance

Attribute

hex (dec)

Pro-

fibus

Index

Param-

eter ID

Data

Type

&

Read/

Write

[`C;Pb]
[ C.Pb]

Control Loop (1 to 2)

Cool Proportional

Band

Set the PID propor-

tional band for the cool

outputs.

0.001 to 9,999.000°F or units

0.001 to 5,555.000°C

25.0°F or

units

14.0°C

Instance 1

Map 1 Map 2

1892 2372

Instance 2

Map 1 Map 2

1962

2442

0x97

(151)

1 to 2

7

67

8012

float

RWES

[`C;hy]
[ C.hy]

Control Loop (1 to 2)

Cool Hysteresis

Set the control switch-

ing hysteresis for on-off

control. This determines

how far into the “on”

region the process value

needs to move before

the output turns on.

0.001 to 9,999.000°F or units

0.001 to 5,555.000°C

3.0°F or

units

2.0°C

Instance 1

Map 1 Map 2

1902 2382

Instance 2

Map 1 Map 2

1972

2522

0x97

(151)

1 to 2

0xC (12)

68

8013

float

RWES

[``ti]
[ ti]

Control Loop (1 to 2)

Time Integral

Set the PID integral for

the outputs.

0 to 9,999 seconds per repeat 180 sec-

onds per

repeat

Instance 1

Map 1 Map 2

1894 2374

Instance 2

Map 1 Map 2

1964

2444

0x97

(151)

1 to 2

8

69

8006

float

RWES

[``td]
[ td]

Control Loop (1 to 2)

Time Derivative

Set the PID derivative

time for the outputs.

0 to 9,999 seconds

0

seconds

Instance 1

Map 1 Map 2

1896 2376

Instance 2

Map 1 Map 2

1966

2446

0x97

(151)

1 to 2

9

70

8007

float

RWES

[``dB]
[ db]

Control Loop (1 to 2)

Dead Band

Set the offset to the

proportional band.

With a negative value,

both heating and cool-

ing outputs are active

when the process value

is near the set point.

A positive value keeps

heating and cooling out-

puts from fighting each

other.

-1,000.0 to 1,000.0°F or units

-556 to 556°C

0

Instance 1

Map 1 Map 2

1898 2378

Instance 2

Map 1 Map 2

1968

2448

0x97

(151)

1 to 2

0xA (10)

71

8008

float

RWES

[t;tUn]
[t.tUn]

Control Loop (1 to 2)

TRU-TUNE+™ Enable

Enable or disable the

TRU-TUNE+™ adap-

tive tuning feature.

[``no]

No (59)

[`YES}

Yes (106)

No

Instance 1

Map 1 Map 2

1910

2390

Instance 2

Map 1 Map 2

1980 2460

0x97 (151)

1 to 2

0x10 (16)

- - - -

8022

uint

RWES

Note:
Some values will be rounded off to fit in the four-character display. Full values can be read
with other interfaces.

R: Read

W: Write

E:

EEPROM

S:

User

Set
