Watlow EZ-ZONE
®
PM Integrated Controller
•
48
•
Chapter 4 Home Page
Possible
Home Page Defaults
(Dependent on Part Number)
Home Page
Display
Parameter Page and Menu
If 9
th
digit of part number is equal to: PM _ _ _ _ _ - _ [A, C, J, R, P, T] _ _ _ _ _
3
Active Process Value (2)
[pu;a2]
Operations Page, Monitor Menu
4
Closed Loop Set Point (2)
[C;sp2]
Operations Page, Monitor Menu
5
Control Mode (1)
[C;M1]
Operations Page, Monitor Menu
If 9
th
digit of part number is equal to: PM _ _ _ _ _ - _ [A, C, J, R, P, T] _ _ _ _ _
6
Heat Power (1)
[h;pr1]
Operations Page, Monitor Menu
7
Cool Power (1)
[C;pr1]
Operations Page, Monitor Menu
8
Autotune (1)
[aut1]
Operations Page, Loop Menu
9
Idle Set Point(1)
[id;s1]
Operations Page, Loop Menu
10 Control Mode (2)
[C;m2]
Operations Page, Monitor Menu
11 Heat Power (2)
[h;pr2]
Operations Page, Monitor Menu
12 Cool Power (2)
[C;pr2]
Operations Page, Monitor Menu
13 Autotune (2)
[aut2]
Operations Page, Loop Menu
14 Idle Set Point (2)
[id;s2]
Operations Page, Loop Menu
15 Limit Low Set Point
[ll;s1]
Operations Page, Limit Menu
16 Limit High Set Point
[lh;s1]
Operations Page, Limit Menu
17 Profile Start
[p;st1]
18 Action Request
[p;aC1]
19 None
20 None
Note:
The numerical digit shown in the prompts (last digit) and within the parenthesize above, represents the pa-
rameter instance and can be greater than one.
Conventions Used in the Menu Pages
To better understand the menu pages that follow review the naming conventions used. When encountered
throughout this document, the word "default" implies as shipped from the factory. Each page (Operations,
Setup, Profile and Factory) and their associated menus have identical headers defined below:
Header Name
Definition
Display
Visually displayed information from the control.
Parameter Name
Describes the function of the given parameter.
Range
Defines options available for this prompt, i.e., min/max values (numerical), yes/
no, etc... (further explanation below).
Default
Values as delivered from the factory.
Modbus Relative Ad-
dress
Identifies unique parameters using either the Modbus RTU or Modbus TCP pro-
tocols (further explanation below).
CIP (Common Indus-
trial Protocol)
Identifies unique parameters using either the DeviceNet or EtherNet/IP protocol
(further explanation below).
Profibus Index
Identifies unique parameters using Profibus DP protocol (further explanation be-
low).
Parameter ID
Identifies unique parameters used with other software such as, LabVIEW.
