Watlow EZ-ZONE ® PM Integrated Controller • 62 • Chapter 5 Operations Page
Operations Page
Dis-
play
Parameter name
Description
Range Default
Modbus
Relative Ad-
dress
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Param-
eter ID
Data
Type
& Read/
Write
[a;sir]
[A.Sir] Alarm (1 to 4)
Alarm Silence Request
Write to this register to
silence an alarm
Note:
If an alarm is setup
to silence alarm when
active [a;sir] will ap-
pear on the display.
[`sil] Silence Alarm
(1010)
Instance 1
Map 1 Map 2
1506 1906
Offset to next
instance (Map1
1 equals +50,
Map 2 equals
+60)
0x6D
(109)
1 to 4
0xE (14)
- - - - 9014 uint
W
[`a;st]
[ A.St] Alarm (1 to 4)
Alarm State
Current state of alarm
[`Str] Startup (88)
[nonE] None (61)
[`bLo] Blocked (12)
[`AL;l] Alarm low (8)
[`AL;h] Alarm high (7)
[`Err] Error (28)
Instance 1
Map 1 Map 2
1496 1896
Offset to next
instance [Map1
+50], [Map 2
+60]
0x6D
(109)
1 to 4
9
- - - - 9009 uint
R
No
Dis-
play
Alarm (1 to 4)
Alarm Clearable
Indicates if alarm can be
cleared.
[``no] No (59)
[`YES] Yes (106)
Instance 1
Map 1 Map 2
1502 1902
Offset to next
instance (Map1
1 equals +50,
Map 2 equals
+60)
0x6D
(109)
1 to 4
0xC (12)
- - - - 9012 uint
R
No
Dis-
play
Alarm (1 to 4)
Alarm Silenced
Indicates if alarm is
silenced.
[`YES] Yes (106)
[``no] No (59)
- - - - Instance 1
Map 1 Map 2
1500 1900
Offset to next
instance (Map1
1 equals +50,
Map 2 equals
+60)
0x6D
(109)
1 to 4
0x0B (11)
- - - - 9011 uint
R
No
Dis-
play
Alarm (1 to 4)
Alarm Latched
Indicates if alarm is
latched.
[`yes] Yes (106)
[``no] No (59)
- - - - Instance 1
Map 1 Map 2
1498 1898
Offset to next
instance (Map1
1 equals +50,
Map 2 equals
+60)
0x6D
(109)
1 to 4
0x0A (10)
- - - - 9010 uint
R
[CUrr]
[oPEr]
Current Menu
[`C;hi]
[ C.hi] Current (1)
Current High Set
Point
Set the current value
that will trigger a high
heater error state.
-1,999.000 to 9,999.000 50.0 Instance 1
Map 1 Map 2
1134 1374
0x73 (115)
1
8
- - - - 15008 float
RWES
Note:
Some values will be rounded off to fit in the four-character display. Full values can
be read with other interfaces. R: Read
W: Write
E: EEPROM
S: User
Set
