Watlow EZ-ZONE

®

PM Integrated Controller

56

Chapter 5 Operations Page

Operations Page

Dis-

play

Parameter name

Description

Range

Default

Modbus

Relative Ad-

dress

CIP

Class

Instance

Attribute

hex (dec)

Profibus

Index

Param-

eter ID

Data

Type

& Read/

Write

[``o;u]
[ o.v]

Process Value (1 to 2)

Output Value

View the value of this

function block's output.

-1,999.000 to 9,999.000°F

or units

-1,128.000 to 5,537.000°C

0.0

Instance 1

Map 1

Map 2

- - - -

3322

Instance 2

Map 1

Map 2

- - - -

3392

0x7E (126)

1 to 2

0x16 (22)

- - - -

26022 float

R

No

Dis-

play

Process Value (1 to 2)

Output Error

View reported cause for

Process output malfunc-

tion.

[none]

None (61)

[open]

Open (65)

[shrt]

Shorted (127)

[`e;m]

Measurement er-

ror (140)

[e;Cal]

Bad calibration

data (139)

[er;ab]

Ambient error (9)

[e;rtd]

RTD error (14)

[fail]

Fail (32)

[e;rm]

Math error (1423)

[Nsrc]

Not sourced (246)

[stal]

Stale (1617)

[no;pr]

Can't process

(1659)

None

Instance 1

Map 1 Map 2

- - - -

3332

Instance 2

Map 1 Map 2

- - - -

3402

0x86 (134)

1 to 2

0x1B (27)

- - - -

26027

uint

R

[`dio]
[oPEr]
Digital Input/Output Menu

[`do;S]
[ do.S]

Digital Output (5 to 12)

Output State

View the state of this

output.

[`off]

Off (62)

[``on]

On (63)

Instance 5

Map 1

Map 2

1012 1132

Offset to next

instance equals

+30

0x6A (106)

5 to C (12)

7

90

6007

uint

R

[`di;S]
[ di.S]

Digital Input (5 to 12)

Input State

View this event input

state.

[`off]

Off (62)

[``on]

On (63)

- - - -

Instance 5

Map 1

Map 2

1020 1140

Offset to next

instance equals

+30

0x6A (106)

5 to C (12)

0xB (11)

- - - -

6011

uint

R

[`ei;S]
[ Ei.S]

Digital Input (5 to 6)

Event Status

View this event input

state.

[`iact]

Inactive (41)

[``act]

Active (5)

Instance 5

Map 1

Map 2

1408 1648

Offset to next

instance equals

+20

0x6E (110)

5 to 6

5

140

10005 uint

R

[`ei;S]
[ Ei.S]

Digital Input (7 to 12)

Event Status

View this event input

state.

[`iact]

Inactive (41)

[``act]

Active (5)

Instance 7

Map 1

Map 2

1448 1688

Offset to next

instance equals

+20

0x6E (110)

7 to C (12)

5

140

10005 uint

R

No Dis-

play

EZ-Key/s (1 to 2)

Event Status

View this event input

state.

[`iact]

Inactive (41)

[``act]

Active (5)

Off

Instance 1

Map 1

Map 2

1328 1568

Instance 2

Map 1

Map 2

1348

1588

0x6E (110)

3 to 4

5

140

10005 uint

R

Note:
Some values will be rounded off to fit in the four-character display. Full values can
be read with other interfaces.

R: Read

W: Write

E: EEPROM

S: User

Set
