Watlow EZ-ZONE

®

PM Integrated Controller

116

Chapter 8 Factory Page

Factory Page

Dis-

play

Parameter Name

Description

Range

Default

Modbus

Relative Ad-

dress

CIP

Class

Instance

Attribute

hex (dec)

Pro-

fibus

Index

Param-

eter ID

Data

Type

&

Read/

Write

[ULoC]
[FCty]
Unlock Menu

[Code]
[CodE]

Security Setting

Public Key

If Rolling Password

turned on, generates a

random number when

power is cycled. If Roll-

ing Password is off

fixed number will be

displayed. The key can

be used to gain access

when password is not

known.

Customer Specific

0

- - - -

- - - -

- - - -

3020

uint

R

[pass]
[PASS]

Security Setting

Password

Enter the User or Ad-

ministrator password to

gain access. After valid

password is supplied

exit this menu and re-

enter the Security Menu

via the Factory Page.

-1999 to 9999

0

- - - -

- - - -

- - - -

3022

int

RW

[diag]
[FCty]
Diagnostics Menu

[``Pn]
[ Pn]

Diagnostics

Part Number

Display this controller's

part number.

15 characters

- - - -

- - - -

0x65

(101)

1

9

115

1009

string

R

[`rEu]
[ rEu]

Diagnostics

Software Revision

Display this control-

ler's firmware revision

number.

1 to 10

- - - -

Instance 1

Map 1 Map 2

4 4

0x65

(101)

1

3

116

1003

string

R

[S;bLd]
[S.bLd]

Diagnostics

Software Build Num-

ber

Display the firmware

build number.

0 to 2,147,483,647

- - - -

Instance 1

Map 1 Map 2

8 8

0x65

(101)

1

5

- - - -

1005

dint

R

[``Sn]
[ Sn]

Diagnostics

Serial Number

Display the serial num-

ber.

0 to 2,147,483,647

- - - -

Instance 1

Map 1 Map 2

12 12

0x65

(101)

1

0x20 (32)

- - - -

1032

string

R

[dAtE]
[dAtE]

Diagnostics

Date of Manufacture

Display the date code

(YYWW). Where YY =

year and WW= week..

0 to 2,147,483,647

- - - -

Instance 1

Map 1

Map 2

14

14

0x65

(101)

1

8

- - - -

1008

dint

R

No Dis-
play

Diagnostics

Hardware ID

Display the Hardware

ID.

0 to 2,147,483,647

- - - -

Instance 1

Map 1

Map 2

0

0

0x65

(101)

1

1

- - - -

1001

dint

R

No Dis-
play

Diagnostics

Firmware ID

Display the Firmware

ID.

0 to 2,147,483,647

- - - -

Instance 1

Map 1

Map 2

2

2

0x65

(101)

1

2

- - - -

1002

dint

R

[iP;aC]
[iP.AC]

Diagnostics

IP Address Mode

Actual address mode

(DHCP or Fixed).

[dhCP]

DHCP (1281)

[F;Add]

Fixed Address (1284)

DHCP

- - - -

- - - -

- - - -

17013 - - - -

Note:

Some values will be rounded off to fit in the four-character display. Full values can be read
with other interfaces.

If there is only one instance of a menu, no submenus will appear.

R: Read

W: Write

E:

EEPROM

S:

User

Set
