Watlow EZ-ZONE

®

PM Integrated Controller

115

Chapter 8 Factory Page

Factory Page

Dis-

play

Parameter Name

Description

Range

Default

Modbus

Relative Ad-

dress

CIP

Class

Instance

Attribute

hex (dec)

Pro-

fibus

Index

Param-

eter ID

Data

Type

&

Read/

Write

[rLoC]
[rLoC]

Security Setting

Read Lock

Set the read security

clearance level. The

user can access the

selected level and all

lower levels.

If the Set Lockout Secu-

rity level is higher than

the Read Lockout Secu-

rity, the Read Lockout

Security level takes

priority.

1 to 5

5

Instance 1

Map 1

Map 2

1848 2318

0x67 (103)

1

0x0A (10)

- - - -

3010

uint

RWE

[SLoC]
[SLoC]

Security Setting

Write Security

Set the write security

clearance level. The

user can access the

selected level and all

lower levels.

If the Set Lockout Secu-

rity level is higher than

the Read Lockout Secu-

rity, the Read Lockout

Security level takes

priority.

0 to 5

5

Instance 1

Map 1

Map 2

1844 2314

0x67 (103)

1

0x0B (11)

- - - -

3011

uint

RWE

[loC;l]
[LoC.L]

Security Setting

Locked Access Level

Determines user level

menu visibility when

Password Enable is set

to on. See Features sec-

tion under Password

Security.

1 to 5

5

- - - -

- - - -

- - - -

3016

uint

RWE

[roll]
[roLL]

Security Setting

Rolling Password

When power is cycled

a new Public Key will

be displayed and User

Password changes.

[`off]

Off

[``on]

On

Off

- - - -

- - - -

- - - -

3019

uint

RWE

[pas;u]
[PAS.u]

Security Setting

User Password

Used to acquire access

to menus made avail-

able through the Locked

Access Level setting.

10 to 999

63

- - - -

- - - -

- - - -

3017

uint

RWE

[pas;a]
[PAS.A]

Security Setting

Administrator Pass-

word

Used to acquire full ac-

cess to all menus includ-

ing disabling or chang-

ing passwords.

10 to 999

156

- - - -

- - - -

- - - -

3018

uint

RWE

Note:

Some values will be rounded off to fit in the four-character display. Full values can be read
with other interfaces.

If there is only one instance of a menu, no submenus will appear.

R: Read

W: Write

E:

EEPROM

S:

User

Set
