4 Networking Switch Modules 496
MSTP Statistics
The MSTP Statistics link allows you to view MSTP statistics through the
following pages:
•
“MSTP Information” on page 496
• “MSTP CIST Statistics” on page 497
• “MSTP MSTI Port Statistics” on page 499
MSTP Information
Clicking the I
NFORMATION
tab brings up the MSTP I
NFORMATION
page,
which displays MSTP statistics. The parameters for this page are shown
in the following table.
Parameter Description
Bridge Address This parameter specifies the Bridge Address.
CIST Root This parameter specifies the CIST root.
Regional Root This parameter specifies the Regional root.
CIST Root Cost This parameter specifies the CIST root cost.
Regional Root Cost This parameter specifies the Regional root cost.
Root Port This parameter specifies the index of the root port.
