2 Chassis Enclosure 84
Power Components
Power components for the AB7000 system’s power supplies are shown
below in Figure 2-49 and described in the following table.
Figure 2-49. Power Components
Note: You can choose either a PDU with extension cord or an AC
power cord for your blade system. Please consult your sales
representative regarding your most suitable solution.
Power Cord
Each 2500W power supply module has its own power cord with a C19
type connector (IEC-60320-C19) to connect to the power supply. The
Item Name Description
1 PDU Power Distribution Unit (NEMA L6 Plug)
2 Power
Cord Extension Cord (connection from power supply module
to PDU)
3 AC P ower
Cord
Connection from power supply module to socket.
2
1
2
1
3 3
