325
QoS Policymap Settings
Clicking the P
OLICYMAP
tab brings up the Q
O
S P
OLICYMAP
S
ETTINGS
page,
which is used to specify action for a specified classmap. The parameters
for this page are shown in the following table.
Filter Type This parameter specifies the filter type associated with
the Classmap. It can be set as either
MAC filter (1) or IP
filter (2) .
Figure 4-208. QoS Policymap Settings
Parameter Description
Policy Map ID This parameter specifies the unique ID for Policymap.
The value ranges between
1 and 65535.
Class Map ID This parameter specifies the C LASS M AP ID to associate
with Policymap.
Traffic Rate This parameter specifies the T
RAFFIC
R
ATE
of data that
has to be applied.
Parameter Description
