90
2588B–AVR–11/06
ATtiny261/461/861
When this bit is set (one), the Timer/Counter prescaler (TCNT1 is unaffected) will be reset. The
bit will be cleared by hardware after the operation is performed. Writing a zero to this bit will have
no effect. This bit will always read as zero.
• Bits 3:0 - CS13, CS12, CS11, CS10: Clock Select Bits 3, 2, 1, and 0
The Clock Select bits 3, 2, 1, and 0 define the prescaling source of Timer/Counter1.
The Stop condition provides a Timer Enable/Disable function.
Table 15-1. Timer/Counter1 Prescale Select
CS13 CS12 CS11 CS10
Asynchronous
Clocking Mode
Synchronous
Clocking Mode
0 0 0 0 T/C1 stopped T/C1 stopped
0 0 0 1 PCK CK
0 0 1 0 PCK/2 CK/2
0 0 1 1 PCK/4 CK/4
0 1 0 0 PCK/8 CK/8
0 1 0 1 PCK/16 CK/16
0 1 1 0 PCK/32 CK/32
0 1 1 1 PCK/64 CK/64
1 0 0 0 PCK/128 CK/128
1 0 0 1 PCK/256 CK/256
1 0 1 0 PCK/512 CK/512
1 0 1 1 PCK/1024 CK/1024
1 1 0 0 PCK/2048 CK/2048
1 1 0 1 PCK/4096 CK/4096
1 1 1 0 PCK/8192 CK/8192
1 1 1 1 PCK/16384 CK/16384
