206
2588B–AVR–11/06
ATtiny261/461/861
Figure 24-21. I/O Pin Output Voltage vs. Source Current (V
CC
= 3V)
Figure 24-22. I/O Pin Output Voltage vs. Source Current (V
CC
= 5V)
I/O PIN OUTPUT VOLTAGE vs. SOURCE CURRENT
V
CC
= 3V
85 ˚C
25 ˚C
-40 ˚C
1,5
1,7
1,9
2,1
2,3
2,5
2,7
2,9
3,1
0 5 10 15 20 25
I
OH
(mA)
V
OH
(V)
I/O PIN OUTPUT VOLTAGE vs. SOURCE CURRENT
V
CC
= 5V
85 ˚C
25 ˚C
-40 ˚C
4
4,2
4,4
4,6
4,8
5
0 5 10 15 20 25
I
OH
(mA)
V
OH
(V)
