ATtiny261/461/861
Figure 24-37. AREF External Reference Current vs. V
CC
Figure 24-38. Analog Comparator vs. V
CC
AREF EXTERNAL REFERENCE CURRENT vs. V
CC
25 ˚C
0
30
60
90
120
150
180
1,5 2 2,5 3 3,5 4 4,5 5 5,5
V
CC
(V)
I CC
(uA)
ANALOG COMPARATOR vs. V
CC
25 ˚C
0
20
40
60
80
100
120
140
160
1,5 2 2,5 3 3,5 4 4,5 5 5,5
V
CC
(V)
I CC
