Figure 24-35. Calibrated 8.0 MHz RC Oscillator Frequency vs. OSCCAL Value
24.10 Current Consumption of Peripheral Units
Figure 24-36. ADC Current vs. V
CC
(AREF = AV
CC
)
CALIBRATED 8.0 MHz RC OSCILLATOR FREQUENCY vs. OSCCAL VALUE
85 ˚C
25 ˚C
-40 ˚C
0
2
4
6
8
10
12
14
16
18
0 16 32 48 64 80 96 112 128 144 160 176 192 208 224 240 256
OSCCAL (X1)
F RC
(MHz)
ADC CURRENT vs. V
CC
AREF = AV
CC
0
100
200
300
400
500
600
700
800
900
1000
1,5 2 2,5 3 3,5 4 4,5 5 5,5
V
CC
(V)
I CC
(uA)
25 ˚C
