ATmega32/64/M1/C1
Figure 26-41. Aref Current vs. V
CC
(ADC at 1 MHz)
Figure 26-42. Analog Comparator Current vs. V
CC
AREF vs. V
CC
ADC AT 1 MHz
85 ˚C
25 ˚C
-40 ˚C
0
20
40
60
80
100
120
140
160
180
1.5 2 2.5 3 3.5 4 4.5 5 5.5
V
CC
(V)
I CC
(uA)
ANALOG COMPARATOR CURRENT vs. V
CC
105 °C
85 °C
25 °C
-40 °C
0
10
20
30
40
50
60
70
80
2 2,5 3 3,5 4 4,5 5 5,5
V
CC
(V)
I CC
(uA)
