26.11 Current Consumption of Peripheral Units
Figure 26-39. Brownout Detector Current vs. V
CC
Figure 26-40. ADC Current vs. V
CC
(ADC at 50 kHz)
BROWNOUT DETECTOR CURRENT vs. V
CC
105 °C
85 °C
25 °C
-40 °C
0
5
10
15
20
25
30
35
40
45
2 2,5 3 3,5 4 4,5 5 5,5
V
CC
(V)
I CC
(uA)
AREF vs. V
CC
ADC AT 50 KHz
85 °C
25 °C
-40 °C
150
200
250
300
350
400
450
500
1.5 2 2.5 3 3.5 4 4.5 5 5.5
V
CC
(V)
I CC
(uA) TE
