333
7647A–AVR–02/08
ATmega32/64/M1/C1
Figure 26-23. Reset Input Threshold Voltage vs. V
CC
(VIH, Reset Pin Read As '1')
Figure 26-24. Reset Input Threshold Voltage vs. V
CC
(VIL, Reset Pin Read As '0')
RESET INPUT THRESHOLD VOLTAGE vs. V
CC
VIH, RESET PIN READ AS '1'
105 °C
85 °C
25 °C
-40 °C
0
0,5
1
1,5
2
2,5
2 2,5 3 3,5 4 4,5 5 5,5
V
CC
(V)
Threshold (V)
RESET INPUT THRESHOLD VOLTAGE vs. V
CC
VIL, RESET PIN READ AS '0'
105 °C
85 °C
25 °C
-40 °C
0
0,5
1
1,5
2
2,5
2 2,5 3 3,5 4 4,5 5 5,5
V
CC
(V)
Threshold (V)
