background image

192

7647A–AVR–02/08

ATmega32/64/M1/C1

• Bit 7– Reserved Bit

This bit is reserved for future use. For compatibility with future devices, it must be written to zero
when CANBT3 is written.

• Bit 6:4 – PHS22:0: Phase Segment 2

This phase is used to compensate for phase edge errors. This segment may be shortened by
the re-synchronization jump width. PHS2[2..0] shall be

1 and

PHS1[2..0] (c.f.

Section 16.2.3

“CAN Bit Timing” on page 169

and

Section 16.4.3 “Baud Rate” on page 175

).

• Bit 3:1 – PHS12:0: Phase Segment 1

This phase is used to compensate for phase edge errors. This segment may be lengthened by
the re-synchronization jump width.

• Bit 0 – SMP: Sample Point(s)

This option allows to filter possible noise on TxCAN input pin.

– 0 - the sampling will occur once at the user configured sampling point - SP.

– 1 - with three-point sampling configuration the first sampling will occur two

T

clk

IO

clocks before the user configured sampling point - SP, again at one

T

clk

IO

clock

before SP and finally at SP. Then the bit level will be determined by a majority vote of
the three samples.

‘SMP=1’ configuration is not compatible with ‘BRP[5:0]=0’ because TQ =

T

clk

IO

.

If BRP = 0, SMP must be cleared.

16.10.11 CAN Timer Control Register - CANTCON

• Bit 7:0 – TPRSC7:0: CAN Timer Prescaler

Prescaler for the CAN timer upper counter range 0 to 255. It provides the clock to the CAN timer
if the CAN controller is enabled.

T

clk

CANTIM

=

T

clk

IO

x 8 x (CANTCON [7:0] + 1)

16.10.12 CAN Timer Registers - CANTIML and CANTIMH

• Bits 15:0 - CANTIM15:0: CAN Timer Count

CAN timer counter range 0 to 65,535.

Tphs2 = Tscl x (PHS2 [2:0] + 1)

Tphs1 = Tscl x (PHS1 [2:0] + 1)

Bit

7

6

5

4

3

2

1

0

TPRSC7

TPRSC6

TPRSC5

TPRSC4

TPRSC3

TPRSC2

TRPSC1

TPRSC0

CANTCON

Read/Write

R/W

R/W

R/W

R/W

R/W

R/W

R/W

R/W

Initial Value

0

0

0

0

0

0

0

0

Bit

7

6

5

4

3

2

1

0

CANTIM7

CANTIM6

CANTIM5

CANTIM4

CANTIM3

CANTIM2

CANTIM1 CANTIM0

CANTIML

CANTIM15 CANTIM14 CANTIM13 CANTIM12 CANTIM11 CANTIM10 CANTIM9 CANTIM8

CANTIMH

Bit

15

14

13

12

11

10

9

8

Read/Write

R

R

R

R

R

R

R

R

Initial Value

0

0

0

0

0

0

0

0
