ATmega32/64/M1/C1
Figure 26-3. Active Supply Current vs. V
CC
(Internal RC Oscillator, 8 MHz)
Figure 26-4. Active Supply Current vs. V
CC
(Internal PLL Oscillator, 16 MHz)
ACTIVE SUPPLY CURRENT vs. V
CC
INTERNAL RC OSCILLATOR, 8 MHz
105 °C
85 °C
25 °C
-40 °C
0
1
2
3
4
5
6
7
8
9
2 2,5 3 3,5 4 4,5 5 5,5
V
CC
(V)
I CC
(mA
)
ACTIVE SUPPLY CURRENT vs. V
CC
INTERNAL PLL OSCILLATOR, 16 MHz
105 °C
85 °C
25 °C
-40 °C
0
2
4
6
8
10
12
14
16
18
20
2 2,5 3 3,5 4 4,5 5 5,5
V
CC
(V)
I CC
(m
A
)
