337
7647A–AVR–02/08
ATmega32/64/M1/C1
Figure 26-31. BOD Thresholds vs. Temperature (BODLEVEL Is 2.7V)
Figure 26-32. TypicalAnalog Comparator Hysterisis Average Thresholds vs. Common Mode
Voltage
BOD THRESHOLDS vs. TEMPERATURE
BODLV IS 2.7 V
Rising Vcc
Falling Vcc
2,68
2,7
2,72
2,74
2,76
2,78
2,8
2,82
-50 -40 -30 -20 -10 0 10 20 30 40 50 60 70 80 90 100 110 120
Temperature (C)
Threshold (V)
-60.00E-3
-50.00E-3
-40.00E-3
-30.00E-3
-20.00E-3
-10.00E-3
000.00E+0
10.00E-3
20.00E-3
30.00E-3
40.00E-3
0.5 1 1.35 1.5 2 2.5 2.6 2.75 3 3.5 4 4.5 5 5.4
Common voltage (v)
th
res
h
ol
d
val
u
e
(V
)
