W90N745CD/W90N745CDG
- 150 -
31 30 29 28 27 26 25 24
CRXBSA
23 22 21 20 19 18 17 16
CRXBSA
15 14 13 12 11 10 9 8
CRXBSA
7 6 5 4 3 2 1 0
CRXBSA
BITS DESCRIPTIONS
[31:0] CRXBSA Current Receive Buffer Start Address
Receive Finite State Machine Register (RXFSM)
The RXFSM shows the current value of the FSM (Finite State Machine) of RxDMA and RxFIFO
controller. The RXFSM is read only and write to it has no effect. The RXFSM is used only for debug.
REGISTER ADDRESS R/W DESCRIPTION RESET VALUE
RXFSM 0xFFF0_3200 R Receive Finite State Machine Register 0x0081_1101
31 30 29 28 27 26 25 24
RX_FSM
23 22 21 20 19 18 17 16
RX_FSM Reserved RxBuf_FSM
15 14 13 12 11 10 9 8
RXFetch_FSM RXClose_FSM
7 6 5 4 3 2 1 0
RFF_FSM
