ZyWALL 5/35/70 Series User’s Guide
92 Chapter 3 Wizard Setup
3.2.1.2 PPPoE Encapsulation
Point-to-Point Protocol over Ethernet (PPPoE) functions as a dial-up connection. PPPoE is an
IETF (Internet Engineering Task Force) standard specifying how a host personal computer
interacts with a broadband modem (for example DSL, cable, wireless, etc.) to achieve access
to high-speed data networks.
Figure 19 ISP Parameters: PPPoE Encapsulation
The following table describes the labels in this screen.
Back Click Back to return to the previous wizard screen.
Apply Click Apply to save your changes and go to the next screen.
Table 12 ISP Parameters: Ethernet Encapsulation
LABEL DESCRIPTION
Table 13 ISP Parameters: PPPoE Encapsulation
LABEL DESCRIPTION
ISP Parameter for
Internet Access
Encapsulation Choose an encapsulation method from the pull-down list box. PPP over Ethernet
forms a dial-up connection.
