ZyWALL 5/35/70 Series User’s Guide
146 Chapter 7 Bridge Screens
Figure 60 NETWORK > Bridge > Port Roles
The following table describes the labels in this screen.
After you change the LAN/DMZ/WLAN port roles and click Apply, please wait for few
seconds until the following screen appears. Click Return to go back to the Port Roles screen.
Figure 61 Port Roles Change Complete
Table 30 NETWORK > Bridge > Port Roles
LABEL DESCRIPTION
LAN Select a port’s LAN radio button to use the port as part of the LAN.
DMZ Select a port’s DMZ radio button to use the port as part of the DMZ.
WLAN Select a port’s WLAN radio button to use the port as part of the WLAN.
Apply Click Apply to save your changes back to the ZyWALL.
Reset Click Reset to begin configuring this screen afresh.
