ZyWALL 5/35/70 Series User’s Guide
Chapter 2 Introducing the Web Configurator 73
Status For the LAN, DMZ and WLAN ports, this displays the port speed and duplex
setting. Ethernet port connections can be in half-duplex or full-duplex mode. Full-
duplex refers to a device's ability to send and receive simultaneously, while half-
duplex indicates that traffic can flow in only one direction at a time. The Ethernet
port must use the same speed or duplex mode setting as the peer Ethernet port in
order to connect.
For the WAN and Dial Backup ports, it displays the port speed and duplex setting
if you’re using Ethernet encapsulation and Down (line is down or not connected),
Idle (line (ppp) idle), Dial (starting to trigger a call) or Drop (dropping a call) if
you’re using PPPoE encapsulation.
For the WLAN card, it displays the transmission rate when a wireless LAN card is
inserted and WLAN is enabled or Down when a wireless LAN card is not inserted
or WLAN is disabled.
IP/Netmask This shows the port’s IP address and subnet mask.
IP Assignment For the WAN, if the ZyWALL gets its IP address automatically from an ISP, this
displays DHCP client when you’re using Ethernet encapsulation and IPCP Client
when you’re using PPPoE or PPTP encapsulation. Static displays if the WAN port
is using a manually entered static (fixed) IP address.
For the LAN, WLAN or DMZ, DHCP server displays when the ZyWALL is set to
automatically give IP address information to the computers connected to the LAN.
DHCP relay displays when the ZyWALL is set to forward IP address assignment
requests to another DHCP server. Static displays if the LAN port is using a
manually entered static (fixed) IP address. In this case, you must have another
DHCP server on your LAN, or else the computers must be manually configured.
For the dial backup port, this shows N/A when dial backup is disabled and IPCP
client when dial backup is enabled.
Renew If you are using Ethernet encapsulation and the WAN port is configured to get the
IP address automatically from the ISP, click Renew to release the WAN port’s
dynamically assigned IP address and get the IP address afresh. Click Dial to dial
up the PPTP, PPPoE or dial backup connection. Click Drop to disconnect the
PPTP, PPPoE or dial backup connection.
Security Services
Turbo Card This field displays whether or not a ZyWALL Turbo Card is installed.
Note: The ZyWALL must have a Turbo Card installed and a valid
service subscription to use the IDP and anti-virus features.
IDP/Anti-Virus
Definitions This is the version number of the signatures set that the ZyWALL is using and the
date and time that the set was released. Click the field label to go to the screen
where you can update the signatures. N/A displays when there is no Turbo Card
installed or the service subscription has expired.
IDP/Anti-Virus
Expiration Date This is the date the IDP/anti-virus service subscription expires. Click the field label
to go to the screen where you can update your service subscription.
Anti-Spam
Expiration Date This is the date the anti-spam service subscription expires. Click the field label to
go to the screen where you can update your service subscription.
Content Filter
Expiration Date This is the date the category-based content filtering service subscription expires.
Click the field label to go to the screen where you can update your service
subscription.
Intrusion Detected This displays how many intrusions the ZyWALL has detected since it last started
up. N/A displays when there is no Turbo Card installed or the service subscription
has expired.
Table 4 Web Configurator HOME Screen in Router Mode (continued)
LABEL DESCRIPTION
