ZyWALL 5/35/70 Series User’s Guide
192 Chapter 10 Wireless LAN
10.3 WLAN Static DHCP
This table allows you to assign IP addresses on the WLAN to specific individual computers
based on their MAC addresses.
Every Ethernet device has a unique MAC (Media Access Control) address. The MAC address
is assigned at the factory and consists of six pairs of hexadecimal characters, for example,
00:A0:C5:00:00:02.
To change your ZyWALL’s WLAN static DHCP settings, click NETWORK >WLAN >
Static DHCP. The screen appears as shown.
Allow between
WLAN and WAN
2 Select this check box to forward NetBIOS packets from the WLAN to WAN port 2
and from WAN port 2 to the WLAN.
Clear this check box to block all NetBIOS packets going from the WLAN to WAN
port 2 and from WAN port 2 to the WLAN.
Allow between
WLAN and DMZ Select this check box to forward NetBIOS packets from the WLAN to the DMZ and
from the DMZ to the WLAN. If your firewall is enabled with the default policy set to
block WLAN to DMZ traffic and DMZ to WLAN traffic, you also need to configure
WLAN to DMZ and DMZ to WLAN firewall rules that forward NetBIOS traffic.
Clear this check box to block all NetBIOS packets going from the WLAN to the DMZ
and from the DMZ to the WLAN.
Apply Click Apply to save your changes back to the ZyWALL.
Reset Click Reset to begin configuring this screen afresh.
Table 50 NETWORK > WLAN (continued)
LABEL DESCRIPTION
