ZyWALL 5/35/70 Series User’s Guide
84 Chapter 2 Introducing the Web Configurator
The following table describes the labels in this screen.
2.4.7 Show Statistics: Line Chart
Click the icon in the Show Statistics screen. This screen shows you a line chart of each port’s
throughput statistics.
Table 8 HOME > Show Statistics
LABEL DESCRIPTION
Click the icon to display the chart of throughput statistics.
Port These are the ZyWALL’s interfaces.
Status For the WAN and dial backup ports, this displays the port speed and duplex setting if
you’re using Ethernet encapsulation and Down (line is down), Idle (line (ppp) idle),
Dial (starting to trigger a call) or Drop (dropping a call) if you’re using PPPoE
encapsulation. Dial backup is not available in bridge mode.
For the LAN, DMZ and WLAN ports, this displays the port speed and duplex setting.
For the WLAN card, this displays the transmission rate when a wireless LAN card is
inserted and WLAN is enabled or Down when a wireless LAN is not inserted or
WLAN is disabled.
TxPkts This is the number of transmitted packets on this port.
RxPkts This is the number of received packets on this port.
Tx B/s This displays the transmission speed in bytes per second on this port.
Rx B/s This displays the reception speed in bytes per second on this port.
Up Time This is the total amount of time the line has been up.
System Up Time This is the total time the ZyWALL has been on.
Automatic
Refresh Interval Select a number of seconds or None from the drop-down list box to update all
screen statistics automatically at the end of every time interval or to not update the
screen statistics.
Refresh Click this button to update the screen’s statistics immediately.
