ZyWALL 5/35/70 Series User’s Guide
576 Chapter 35 LAN Setup
Figure 323 Menu 3.1: LAN Port Filter Setup
35.4 TCP/IP and DHCP Ethernet Setup Menu
From the main menu, enter 3 to open Menu 3 - LAN Setup to configure TCP/IP (RFC 1155)
and DHCP Ethernet setup.
Figure 324 Menu 3: TCP/IP and DHCP Setup
From menu 3, select the submenu option TCP/IP and DHCP Setup and press [ENTER]. The
screen now displays
Menu 3.2 - TCP/IP and DHCP Ethernet Setup , as shown next. Not all
fields are available on all models.
Menu 3.1 - LAN Port Filter Setup
Input Filter Sets:
protocol filters=
device filters=
Output Filter Sets:
protocol filters=
device filters=
Press ENTER to Confirm or ESC to Cancel:
Menu 3 - LAN Setup
1. LAN Port Filter Setup
2. TCP/IP and DHCP Setup
Enter Menu Selection Number:
