ZyWALL 5/35/70 Series User’s Guide
Chapter 6 LAN Screens 133
Figure 52 NETWORK > LAN
The following table describes the labels in this screen.
Table 23 NETWORK > LAN
LABEL DESCRIPTION
LAN TCP/IP
IP Address Type the IP address of your ZyWALL in dotted decimal notation. 192.168.1.1 is the
factory default. Alternatively, click the right mouse button to copy and/or paste the
IP address.
IP Subnet Mask The subnet mask specifies the network number portion of an IP address. Your
ZyWALL automatically calculates the subnet mask based on the IP address that
you assign. Unless you are implementing subnetting, use the subnet mask
computed by the ZyWALL.
RIP Direction RIP (Routing Information Protocol, RFC1058 and RFC 1389) allows a router to
exchange routing information with other routers. The RIP Direction field controls
the sending and receiving of RIP packets. Select the RIP direction from Both/In
Only/Out Only/None. When set to Both or Out Only, the ZyWALL will broadcast
its routing table periodically. When set to Both or In Only, it will incorporate the RIP
information that it receives; when set to None, it will not send any RIP packets and
will ignore any RIP packets received. Both is the default.
