ZyWALL 5/35/70 Series User’s Guide
Chapter 1 Getting to Know Your ZyWALL
65
CARD
Green
Off
The wireless LAN is not ready, or has failed.
On
The wireless LAN is ready.
Flashing
The wireless LAN is sending or receiving packets.
LAN 10/100
(ZyWALL 70
only)
Off
The LAN/DMZ is not connected.
Green
On
The ZyWALL has a successful 10Mbps Ethernet connection.
Flashing
The 10M LAN is sending or receiving packets.
Orange
On
The ZyWALL has a successful 100Mbps Ethernet
connection.
Flashing
The 100M LAN is sending or receiving packets.
WAN1/2 10/100
or
WAN 10/100
Off
The WAN connection is not ready, or has failed.
Green
On
The ZyWALL has a successful 10Mbps WAN connection.
Flashing
The 10M WAN is sending or receiving packets.
Orange
On
The ZyWALL has a successful 100Mbps WAN connection.
Flashing
The 100M WAN is sending or receiving packets.
DMZ 10/100
(ZyWALL 70
only)
Off
The LAN/DMZ is not connected.
Green
On
The ZyWALL has a successful 10Mbps Ethernet connection.
Flashing
The 10M LAN is sending or receiving packets.
Orange
On
The ZyWALL has a successful 100Mbps Ethernet
connection.
Flashing
The 100M LAN is sending or receiving packets.
LAN/DMZ 10/
100
(ZyWALL 35
and ZyWALL 5)
Off
The LAN/DMZ is not connected.
Green
On
The ZyWALL has a successful 10Mbps Ethernet connection.
Flashing
The 10M LAN is sending or receiving packets.
Orange
On
The ZyWALL has a successful 100Mbps Ethernet
connection.
Flashing
The 100M LAN is sending or receiving packets.
Table 2 Front Panel Lights (continued)
LED
COLOR
STATUS
DESCRIPTION
