ZyWALL 5/35/70 Series User’s Guide
Chapter 8 WAN Screens 175
8.16 Advanced Modem Setup
8.16.1 AT Command Strings
For regular telephone lines, the default Dial string tells the modem that the line uses tone
dialing. ATDT is the command for a switch that requires tone dialing. If your switch requires
pulse dialing, change the string to ATDP.
For ISDN lines, there are many more protocols and operational modes. Please consult the
documentation of your TA. You may need additional commands in both Dial and Init strings.
8.16.2 DTR Signal
The majority of WAN devices default to hanging up the current call when the DTR (Data
Terminal Ready) signal is dropped by the DTE. When the Drop DTR When Hang Up check
box is selected, the ZyWALL uses this hardware signal to force the WAN device to hang up,
in addition to issuing the drop command ATH.
8.16.3 Response Strings
The response strings tell the ZyWALL the tags, or labels, immediately preceding the various
call parameters sent from the WAN device. The response strings have not been standardized;
please consult the documentation of your WAN device to find the correct tags.
8.17 Configuring Advanced Modem Setup
Click the Edit button in the Dial Backup screen to display the Advanced Setup screen.
Note: Consult the manual of your WAN device connected to your dial backup port for
specific AT commands.
Apply Click Apply to save your changes back to the ZyWALL.
Reset Click Reset to begin configuring this screen afresh.
Table 44 NETWORK > WAN > Dial Backup (continued)
LABEL DESCRIPTION
