ZyWALL 5/35/70 Series User’s Guide
326 Chapter 18 IPSec VPN
Figure 172 SECURITY > VPN > VPN Rules (IKE)
The following table describes the labels in this screen.
Table 92 SECURITY > VPN > VPN Rules (IKE)
LABEL DESCRIPTION
VPN Rules These VPN rules define the settings for creating VPN tunnels for secure
connection to other computers or networks.
Click this icon to add a VPN gateway policy (or IPSec rule).
Gateway Policies The first row of each VPN rule represents the gateway policy.
The gateway policy identifies the IPSec routers at either end of a VPN tunnel
(My ZyWALL and Remote Gateway) and specifies the authentication,
encryption and other settings needed to negotiate a phase 1 IKE SA (click the
edit icon to display the other settings).
My ZyWALL This represents your ZyWALL.
The WAN IP address, domain name or dynamic domain name of your ZyWALL
displays in router mode.
The ZyWALL’s IP address displays in bridge mode.
Remote
Gateway This represents the remote secure gateway.
The IP address, domain name or dynamic domain name of the remote IPSec
router displays if you specify it, otherwise Dynamic displays.
Click this icon to add a VPN network policy.
Network Policies The subsequent rows in a VPN rule are network policies. A network policy
identifies the devices behind the IPSec routers at either end of a VPN tunnel
and specifies the authentication, encryption and other settings needed to
negotiate a phase 2 IPSec SA.
Local Network This is the network behind the ZyWALL. A network policy specifies which
devices (behind the IPSec routers) can use the VPN tunnel.
