ZyWALL 5/35/70 Series User’s Guide
352 Chapter 18 IPSec VPN
Ending IP
Address/Subnet
Mask When the Address Type field is configured to Single Address, this field is N/A.
When the Address Type field is configured to Range Address, enter the end
(static) IP address, in a range of computers on the network behind the remote
IPSec router. When the Address Type field is configured to Subnet Address,
enter a subnet mask on the network behind the remote IPSec router.
Gateway Policy
Information
My ZyWALL When the ZyWALL is in router mode, enter the WAN IP address or the domain
name of your ZyWALL or leave the field set to 0.0.0.0.
The ZyWALL uses its current WAN IP address (static or dynamic) in setting up the
VPN tunnel if you leave this field as 0.0.0.0. If the WAN connection goes down, the
ZyWALL uses the dial backup IP address for the VPN tunnel when using dial
backup or the LAN IP address when using traffic redirect.
The VPN tunnel has to be rebuilt if this IP address changes.
When the ZyWALL is in bridge mode, this field is read-only and displays the
ZyWALL’s IP address.
Remote Gateway
Addr Type the WAN IP address or the domain name (up to 31 characters) of the IPSec
router with which you're making the VPN connection.
Manual Proposal
SPI Type a unique SPI (Security Parameter Index) from one to four characters long.
Valid Characters are "0, 1, 2, 3, 4, 5, 6, 7, 8, and 9".
Encapsulation
Mode Select Tunnel mode or Transport mode from the drop-down list box.
Active Protocol Select ESP if you want to use ESP (Encapsulation Security Payload). The ESP
protocol (RFC 2406) provides encryption as well as some of the services offered
by AH. If you select ESP here, you must select options from the Encryption
Algorithm and Authentication Algorithm fields (described next).
Select AH if you want to use AH (Authentication Header Protocol). The AH protocol
(RFC 2402) was designed for integrity, authentication, sequence integrity (replay
resistance), and non-repudiation but not for confidentiality, for which the ESP was
designed. If you select AH here, you must select options from the Authentication
Algorithm field (described next).
Encryption
Algorithm Select DES, 3DES or NULL from the drop-down list box.
When DES is used for data communications, both sender and receiver must know
the Encryption Key, which can be used to encrypt and decrypt the message or to
generate and verify a message authentication code. The DES encryption algorithm
uses a 56-bit key. Triple DES (3DES) is a variation on DES that uses a 168-bit key.
As a result, 3DES is more secure than DES. It also requires more processing
power, resulting in increased latency and decreased throughput. Select NULL to
set up a tunnel without encryption. When you select NULL, you do not enter an
encryption key.
Authentication
Algorithm Select SHA1 or MD5 from the drop-down list box. MD5 (Message Digest 5) and
SHA1 (Secure Hash Algorithm) are hash algorithms used to authenticate packet
data. The SHA1 algorithm is generally considered stronger than MD5, but is
slower. Select MD5 for minimal security and SHA-1 for maximum security.
Encryption Key This field is applicable when you select ESP in the Active Protocol field above.
With DES, type a unique key 8 characters long. With 3DES, type a unique key 24
characters long. Any characters may be used, including spaces, but trailing spaces
are truncated.
Authentication
Key Type a unique authentication key to be used by IPSec if applicable. Enter 16
characters for MD5 authentication or 20 characters for SHA-1 authentication. Any
characters may be used, including spaces, but trailing spaces are truncated.
Table 99 SECURITY > VPN > VPN Rules (Manual) > Edit (continued)
LABEL DESCRIPTION
