ZyWALL 5/35/70 Series User’s Guide
Chapter 2 Introducing the Web Configurator 77
Port Status For the WAN, LAN, DMZ, and WLAN Interfaces, this displays the port speed and
duplex setting. For the WAN port, it displays Down when the link is not ready or has
failed. For the wireless card, it displays the transmission rate when a wireless LAN
card is inserted and WLAN is enabled or Down when a wireless LAN is not inserted
or WLAN is disabled.
RSTP Status This is the RSTP status of the corresponding port.
RSTP Active This shows whether or not RSTP is active on the corresponding port.
RSTP Priority This is the RSTP priority of the corresponding port.
RSTP Path Cost This is the cost of transmitting a frame from the root bridge to the corresponding
port.
Security Services
Turbo Card This field displays whether or not a ZyWALL Turbo Card is installed.
Note: The ZyWALL must have a Turbo Card installed and a valid
service subscription to use the IDP and anti-virus features.
IDP/Anti-Virus
Definitions This is the version number of the signatures set that the ZyWALL is using and the
date and time that the set was released. Click the field label to go to the screen
where you can update the signatures. N/A displays when there is no Turbo Card
installed or the service subscription has expired.
IDP/Anti-Virus
Expiration Date This is the date the IDP/anti-virus service subscription expires. Click the field label
to go to the screen where you can update your service subscription.
Anti-Spam
Expiration Date This is the date the anti-spam service subscription expires. Click the field label to go
to the screen where you can update your service subscription.
Content Filter
Expiration Date This is the date the category-based content filtering service subscription expires.
Click the field label to go to the screen where you can update your service
subscription.
Intrusion
Detected This displays how many intrusions the ZyWALL has detected since it last started
up. N/A displays when there is no Turbo Card installed or the service subscription
has expired.
Virus Detected This displays how many virus-infected files the ZyWALL has detected since it last
started up. It also displays the percentage of virus-infected files out of the total
number of files that the ZyWALL has scanned (since it last started up). N/A displays
when there is no Turbo Card installed or the service subscription has expired.
Spam Mail
Detected This displays how many spam e-mails the ZyWALL has detected since it last
started up. It also displays the percentage of spam e-mail out of the total number of
e-mails that the ZyWALL has scanned (since it last started up). N/A displays when
the service subscription has expired.
Web Site Blocked This displays how many web site hits the ZyWALL has blocked since it last started
up. N/A displays when the service subscription has expired.
Top 5 Intrusion &
Virus Detections The following is a list of the five intrusions or viruses that the ZyWALL has most
frequently detected since it last started up.
Rank This is the ranking number of an intrusion or virus. This is an intrusion’s or virus’s
place in the list of most common intrusions or viruses.
Intrusion
Detected This is the name of a signature for which the ZyWALL has detected matching
packets. The number in brackets indicates how many times the signature has been
matched.
Click the hyperlink for more detailed information on the intrusion.
Virus Detected This is the name of the virus that the ZyWALL has detected.
Table 5 Web Configurator HOME Screen in Bridge Mode (continued)
LABEL DESCRIPTION
