ZyWALL 5/35/70 Series User’s Guide
Chapter 50 IP Policy Routing 697
Figure 438 IP Routing Policy Example 1
2 Select Yes in the LAN field in menu 25.1.1 to apply the policy to packets received on the
LAN port.
3 Check Menu 25 - IP Routing Policy Summary to see if the rule is added correctly.
4 Create another rule in menu 25.1 for this rule to route packets from any host (IP=0.0.0.0
means any host) with protocol TCP and port FTP access through another gateway
(192.168.1.100).
Menu 25.1 - IP Routing Policy Setup
Rule Index= 1 Active= Yes
Criteria:
IP Protocol = 6
Type of Service= Don't Care Packet length= 10
Precedence = Don't Care Len Comp= Equal
Source:
addr start= 192.168.1.33 end= 192.168.1.64
port start= 0 end= N/A
Destination:
addr start= 0.0.0.0 end= N/A
port start= 80 end= 80
Action= Matched
Gateway Type= IP Address
Gateway addr = 192.168.1.1 Redirect packet= N/A
Type of Service= Max Thruput Log= No
Precedence = 0
Edit policy to packets received from= No
Press ENTER to Confirm or ESC to Cancel:
