ZyWALL 5/35/70 Series User’s Guide
524 Chapter 30 Logs Screens
(L to L/ZW) LAN to LAN/
ZyWALL ACL set for packets traveling from the LAN to the LAN or
the ZyWALL.
(W to W/ZW) WAN to WAN/
ZyWALL ACL set for packets traveling from the WAN to the WAN
or the ZyWALL.
(D to D/ZW) DMZ to DMZ/
ZyWALL ACL set for packets traveling from the DMZ to the DM or
the ZyWALL.
(L to WL) LAN to WLAN ACL set for packets traveling from the LAN to the WLAN.
(WL to L) WLAN to LAN ACL set for packets traveling from the WLAN to the LAN.
(W to WL) WAN to WLAN ACL set for packets traveling from the WAN to the WLAN.
(WL to W) WLAN to WAN ACL set for packets traveling from the WLAN to the WAN.
(D to WL) DMZ to WLAN ACL set for packets traveling from the DMZ to the WLAN.
(WL to D) WLAN to DMZ ACL set for packets traveling from the WLAN to the DMZ.
(WL to WL) WLAN to WLAN/
ZyWALL ACL set for packets traveling from the WLAN to the
WLAN or the ZyWALL.
Table 183 ICMP Notes
TYPE CODE DESCRIPTION
0 Echo Reply
0 Echo reply message
3 Destination Unreachable
0 Net unreachable
1 Host unreachable
2 Protocol unreachable
3 Port unreachable
4 A packet that needed fragmentation was dropped because it was set to Don't
Fragment (DF)
5 Source route failed
4 Source Quench
0 A gateway may discard internet datagrams if it does not have the buffer space
needed to queue the datagrams for output to the next network on the route to
the destination network.
5 Redirect
0 Redirect datagrams for the Network
1 Redirect datagrams for the Host
2 Redirect datagrams for the Type of Service and Network
3 Redirect datagrams for the Type of Service and Host
8 Echo
0 Echo message
Table 182 ACL Setting Notes (continued)
PACKET DIRECTION DIRECTION DESCRIPTION
