STAR LIne Mode Command Specifications
The defined ranges are shown below.
Specifications
c1
c2
Registration count
Japanese Language Kanji characters
c1 = 77h
21h ≤ c2 ≤ 7Eh
94 Characters
They are designed as shown below and data is sent sequentially.
The font of Kanji download characters is composed of 16 x 16 dot patterns.
Bits that correspond to the dots to print are “1,” and the bits that correspond to the dots that are not printed are “0.”
When page mode is selected, only registration is possible.
Printing is possible after switching to line mode.
Registered data is shared by slip and validation.
d1 d3 d5 d7 d9 d11 d13 d15 d17 d19 d21 d23 d25 d27 d29 d31
MSB
LSB
d2 d4 d6 d8 d10 d12 d14 d16 d18 d20 d22 d24 d26 d28 d30 d32
MSB
LSB
Horizontal 16 dot
Vertical
16 dot
