STAR LIne Mode Command Specifications
ESC GS x S 2 n
[Name] Set PDF417 module X direction size
[Code]
ASCII ESC GS x S 2 n
Hexadecimal 1B 1D 78 53 32 n
Decimal 27 29 120 83 50 n
[Defined Area] Thermal : 1 ≤ n ≤ 10
Slip : -
Validation : -
[Initial Value] Thermal : n = 2
Slip : -
Validation : -
[Function]
Parameter details
• n : Sets the module X direction size (x-dim) (units: dots)
Specification using this command is recommended to be 2 ≤ n.
To use with n = 1, confirm by actual use.
,
Only setting is valid
Setting is valid after switching to thermal.
ESC GS x S 3 n
[Name] Set PDF417 module aspect ratio
[Code]
ASCII ESC GS x S 3 n
Hexadecimal 1B 1D 78 53 33 n
Decimal 27 29 120 83 51 n
[Defined Area] Thermal : 1 ≤ n ≤ 10
Slip : -
Validation : -
[Initial Value] Thermal : n = 3
Slip : -
Validation : -
[Function]
Parameter details
• n: Sets module aspect ratio (asp).
The module Y direction size is set to [x-dim * asp] by this command.
Specification using this command is recommended to be 2 ≤ n.
To use with n = 1, confirm by actual use.
,
Only setting is valid
Setting is valid after switching to thermal.
