Rev. 0.00
3-101
STAR Line Mode Command Specifications
k n1 n2 data
[Name] Transfer raster data
[Code]
ASCII k n1 n2 d1 d2 ... dk
Hexadecimal 6B n1 n2 d1 d2 ... dk
Decimal 107 n1 n2 d1 d2 ... dk
[Defined Area] Thermal : 0 ≤ n1 ≤ 255, 0 ≤ n2 ≤ 255, 0 ≤ d ≤ 255
k = n1 + n2 x 256, 1 ≤ k
Slip : -
Validation : -
[Initial Value] Thermal : -
Slip : -
Validation : -
[Function]
Sends raster data.
Raster data is sent in (n1 + n2 x 256) byte counts as binary data.
Raster data exceeding the print area currently set is discarded.
The image buffer expanded position returns to the head of the current dot row without an automatic
line fed after expanding the image buffer data 1 dot row using this command.
Also, data expansion is duplicated on the data in the current image buffer (OR process).
The following shows expanded image buffer for the set raster print color.
n is a decimal description (max. 255 digits) using ASCII characters.
Print color Expanded image buffer
Black Image buffer for black
Cyan Image buffer for color
Magenta Image buffer for color
Yellow Image buffer for color
,
Use prohibited.
