Page 161
Rev. 0.00
3-149
STAR Line Mode Command Specifications
ESC GS h 1 k m n
[Name] Water mark function
[Code]
ASCII
ESC
GS
h
1
k
m
n
Hexadecimal
1B
1D
68
31
k
m
n
Decimal
27
29
104
49
k
m
n
[Defined Area]
Thermal
: 0 ≤ k ≤ 2, 0 ≤ m ≤ 2, 1 ≤ n ≤ 255
Slip
: -
Validation
: -
[Initial Value]
Thermal
: -
Slip
: -
Validation
: -
[Function]
Sets to make water mark function valid/invalid.
k
Water Mark Function
0
Invalid
1
Valid
Prints one logo specified by n at the position centered in the horizontal and vertical
directions.
2
Valid
Repeatedly prints logo specified by n from leading edge of the page to the trailing end of the
page, at the position centered in the horizontal direction.
Set the forming method of the logo data to be printed as the water mark to make the image appropri-
ate as the water mark with this setting.
If the appropriate image is not possible with this setting, re-register after forming the logo data regis-
tered as the water mark as the appropriate data.
m
Water Mark Data Forming
0
Prints logo data specified n as it is.
1
Thins logo data specified n 25% in the printout.
2
Thins logo data specified n 12.5% in the printout.
Specify the registered logo as the water mark.
n
Logo Number
1 to 255
Registered logo number
If the specified logo number is not registered, the water mark will not be printed.
When the water mark inversion function is valid, it is printed by the water mark pinting trigger.
However, this function is executed on print data that fits in the image buffer length.
If print data is larger than the image buffer length, water mark printing is ignored.
Also, when starting printing using anything other than the water mark printing trigger, water mark
printing is ignored.
When in 2-color printing mode, this function is invalid.
This setting is not cleared by the ESC @, CAN commands.
Water Mark Printing Triggers
• Cutter Command
: ESC d n
• FF Command
: FF
• BM Detection Command : ESC d n, FF
• Print Startup Command : ESC GS g 0 m n
• Raster Mode
: When executing FF
