STAR Line Mode Command Specifications
(Note) Registration data shared by all stations, and modes.
If this command is used frequently, there is the possibility of damaging the non-volatile
memory. Write to the non-volatile memory less than 10 times in one day.
Relationship of logo and registered data
xn = xn1 + xn2 x 256, yn = yn1 + yn2 x 256
{ (xn 1 + xn2 x 256) x 8 } dot
(yn1 + yn2 x 256) bite
(yn1 + yn2 x 256) x 8 dot
d(11)
d(12)
d(x1) d(x2) d(xn)
d(21)
d(22) d(n2)
d(n1)
Data
MSB
LSB
