Rev. 0.00
3-120
STAR LIne Mode Command Specifications
ESC GS * 1 h v
[Name] Specify mark height and line feed
[Code]
ASCII ESC GS * 1 h v
Hexadecimal 1B 1D 2A 31 h v
Decimal 27 29 42 49 h v
[Defined Area] Thermal : “001” ≤ h ≤ “255”, “001” ≤ v ≤ “255”, h ≤ v
Slip : -
Validation : -
[Initial Value] Thermal : Non-volatile memory
Slip : -
Validation : -
[Function]
Specifies mark height and line feed
v indicates mark height (number of dots); v indicates mark line feed amount (number of dots).
h, v are ASCII character strings that are expressed in decimal. They are composed of character
codes from “0” to “9.”
If a small line feed amount is specified, there is the possibility that intermittent printing could occur,
so a setting of v = 16 dots or higher is recommended.
,
Only setting is valid
Setting is valid after switching to thermal.
ESC GS * 2 m c w
[Name] Specifies mark color and mark horizontal width in each mark number.
[Code]
ASCII ESC GS * 2 m c w
Hexadecimal 1B 1 D 2A 32 m c w
Decimal 27 29 42 50 m c w
[Defined Area] Thermal : “0” ≤ m ≤ “9”, “0” ≤ c ≤ ”1”, “001” ≤ w ≤ “999”
Slip : -
Validation : -
[Initial Value] Thermal : Non-volatile memory
Slip : -
Validation : -
[Function]
Specifies mark color and mark horizontal width in each mark number.
m indicates the mark number.
c indicates the mark color.
w indicates the mark horizontal width (number of dots).
If w exceeds the currently set print region, this command is ignored.
m, c, w are ASCII character strings that are expressed in decimal. They are composed of character
codes from “0” to “9.”
c Mark Color
“0”(48) White
“1”(49) Black
,
Only setting is valid
Setting is valid after switching to thermal.
