12 Store and Recall RIGOL
DS6000 User’s Guide 12-19
Vertical Expansion Ground
Screen Saver Default
Screen Saver Time OFF
External Trigger
Impedance 1 MΩ
Aux Output TrigOut
Reference Clock ClockOutput
Math Operation Setting (MATHOperation)
Operate
OFF
A+B
Source A
CH1
Source B CH1
Invert OFF
Vertical Scale 2 V
A-B
Source A
CH1
Source B CH1
Invert OFF
Vertical Scale 2 V
A*B
Source A
CH1
Source B CH1
Invert OFF
Vertical Scale 2 U
A/B
Source A
CH1
Source B CH1
Invert OFF
Vertical Scale 2 U
FFT
Source
CH1
Window Function Rectangle
Display Split
Scale dB
Vertical Scale 20.0 dB
Horizontal Scale 2.5 MHz/div
