HEIDENHAIN TNC 410, TNC 426, TNC 430 353
1
0
.9 P
re
a
ssign
e
d Q P
a
ra
met
e
rs
Deviation between actual value and nominal
value during automatic tool measurement with
the TT 130
Tilting the working plane with mathematical
angles (not TNC 410): Rotary axis coordinates
calculated by the TNC
IVth axis
dependent on MP100 Q118
Vth axis (not TNC 410)
dependent on MP100 Q119
Coordinate axis Parameter value
Actual-nominal deviation Parameter value
Tool length Q115
Tool radius Q116
coordinates Parameter value
A axis Q120
B axis Q121
C axis Q122
